SKU:
0925-0176
Manufactured with the help of a computer with cam design capabilities
Made from alloy steel billets and heat-treated processes are utilized
Made in the USA
Four-gear set required for installation.
Installer must check coil bind, valve to valve clearance and valve to piston clearance.
Specs
Exhaust Lift
0.590"
Exhaust Lobe Centerline
108°
Intake Duration
266°
Intake Lift
0.590"
Intake Lobe Centerline
104°
Riding Style
Street
Units
Pair
Application
Intake
Exhaust Close
27°
Exhaust Open
63°
Exhaust Lift at TDC
0.218"
Grind
59 Series
Intake Close
57°
Product Name
Cam Set
Exhaust Duration
270°
Intake Lift at TDC
0.238"
Intake Open
29°
Application
Exhaust
Type
Gear Drive
Part Notes
For 95"+ motors with 10:1 compression ratio or higher.
Maximum torque and HP at middle and upper rpm ranges (2400-6200 rpm).
Coil bind must be checked but can use stock tappets.
Regular price
$476.95
Unit price
Shipping calculated at checkout.
Product Details
Features
- Manufactured with the help of a computer with cam design capabilities
- Made from alloy steel billets and heat-treated processes are utilized
- Made in the USA
- Four-gear set required for installation.
- Installer must check coil bind, valve to valve clearance and valve to piston clearance.
Specs
| Exhaust Lift | 0.590" |
| Exhaust Lobe Centerline | 108° |
| Intake Duration | 266° |
| Intake Lift | 0.590" |
| Intake Lobe Centerline | 104° |
| Riding Style | Street |
| Units | Pair |
| Application | Intake |
| Exhaust Close | 27° |
| Exhaust Open | 63° |
| Exhaust Lift at TDC | 0.218" |
| Grind | 59 Series |
| Intake Close | 57° |
| Product Name | Cam Set |
| Exhaust Duration | 270° |
| Intake Lift at TDC | 0.238" |
| Intake Open | 29° |
| Application | Exhaust |
| Type | Gear Drive |
Part Notes
- For 95"+ motors with 10:1 compression ratio or higher.
- Maximum torque and HP at middle and upper rpm ranges (2400-6200 rpm).
- Coil bind must be checked but can use stock tappets.
Product Description
Features
- Manufactured with the help of a computer with cam design capabilities
- Made from alloy steel billets and heat-treated processes are utilized
- Made in the USA
- Four-gear set required for installation.
- Installer must check coil bind, valve to valve clearance and valve to piston clearance.
Specs
| Exhaust Lift | 0.590" |
| Exhaust Lobe Centerline | 108° |
| Intake Duration | 266° |
| Intake Lift | 0.590" |
| Intake Lobe Centerline | 104° |
| Riding Style | Street |
| Units | Pair |
| Application | Intake |
| Exhaust Close | 27° |
| Exhaust Open | 63° |
| Exhaust Lift at TDC | 0.218" |
| Grind | 59 Series |
| Intake Close | 57° |
| Product Name | Cam Set |
| Exhaust Duration | 270° |
| Intake Lift at TDC | 0.238" |
| Intake Open | 29° |
| Application | Exhaust |
| Type | Gear Drive |
Part Notes
- For 95"+ motors with 10:1 compression ratio or higher.
- Maximum torque and HP at middle and upper rpm ranges (2400-6200 rpm).
- Coil bind must be checked but can use stock tappets.
Part Numbers
| Store SKU | MFR. Product # | Availability |
|---|---|---|
| 0925-0176 | 216359G | In Stock |
Fitment
This product is vehicle specific.
Select your vehicle to confirm fitment.
This Product Fits
Fitment Disclosure
This quick reference fitment information is provided to direct you to our catalog information and the manufacturer's information. Consult manufacturer publication(s) and/or website(s) for specific fitment and application information and other important information. This fitment information is based upon the stock version of the motorcycle or unit referenced and any accessory added or other modification could invalidate the quick reference information provided.
